AirBeast® 200A


  • Atex
  • Counterskin 110
  • Tapping capacity m48
  • Twist drill 45
  • Core drilling 200

For use in the most hazardous of environments.

  • ATEX Class II approved – for use in the most hazardous of environments.
  • 200 mm diameter cutter capacity.
  • M48 tapping capacity.
  • Impressive 2 speed gear box with forward and reverse increasing flexibilty of use.
  • 400 mm drill travel – for demanding drilling applications.
  • Rugged one piece slide and gear box – for extra stability.
  • Double permanent magnetic base – suitable for clamping to pipe and radius surfaces.


Designed to meet the most challenging hole making applications in challenging environments, the AirBeast® 200A is an ATEX Class II approved pneumatic drill, featuring 200mm diameter cutting capacity.

Gallery


AirBeast® 200ASPECIFICATIONS


Model AirBeast® 200A
Spindle 5MT (1-1/4” shank)
Weight 130 kg
Air consumption 3500 l/min (125 CFM)
Pressure 6.5 bar
Max Stroke 400 mm
Cutter Capacity 200 mm Ø x 4” depth of cut
Motor 3650 W
RPM 2 Fixed Speeds no load 140/35 RPM loaded 80/20 RPM
Twist Drill Capacity 45 mm
Tapping Capacity M48
Height min/max 991 / 1391 mm
Length x Width 764 x 485 mm
Magnetic Base L x W 250 x 110 mm
Magnet Deadlift 2 x 1530 kg on 25 mm Plate (2 x 15000 N)
Noise Level < 90dB
Vibration Level < 2.5 m/s2
Voltage/ Part no DRILL-AIR200A
Shipping Weight 150 kg
Shipping Dimensions 510 x 320 x 160 mm
